Model//CHJ-D-301

----------------------------------------------------

This separable forming machine is suitable for products in one shape but witch different sizes. One side of the machine is fixed and other side can be separated. Itis easy to disassemble and assemble and will save machining cost for products in small quantity but in various shapes, suitable for room division, column and upper and lower trough. It's really a forming machine of cost-saving and manpower-saving.



SHEET THICKNESS

0.3∼1.6mm

FORMING SPEED
20∼35m
PER MINUTE
ROLLER SHAFT DIA
φ50∼70mm
ROLLER STATIONS
上UP
12∼25
下DOWN
MOTOR OUTPUT
7.5∼20hp
LENGTH × WIDTH
L 6 ~ 12M
W 1∼1.6M
SINGLE HEAD UNCOILER
2∼3.5Ton
